Descripción
Key Specification View More
Fixed Service Ports
- 48 × 10/100/1000BASE-T ports
- 4 × 1GE/2.5GE SFP ports
Management port
- 1 x RJ45 console port
Switching capacity
- 116 Gbps
Forwarding rate
- 87 Mpps
Capacity of MAC address table
- 16000
Power module
- 1 x fixed power module
Fan module
- 2 x fan module
Cooling mode
- Fan cooling
Input power
- Rated input voltage range: 100V AC to 240V AC, 50/60Hz
- Max. input voltage range: 90V AC to 264V AC, 50/60Hz
Power consumption
- 30W
Surge protection
- 10 kV
Dimensions (W x D x H)
- 440 mm × 220 mm × 43.5 mm (17.32 in. x 8.66 in. × 1.71 in.)
Temperature
- Operating temperature: 0°C to 45°C (32°F to 113°F)
- Storage temperature: –40°C to +70°C (–40°F to +158°F)
Warranty
- 3 years
