Descripción
Key Specification
Electrical
- Operating Voltage: 3.14 V to 3.46 V
- Max. Power Consumption: 1.5 W
Environmental
- Operating Temperature: 0°C to 70°C (32°F to 158°F)
- Storage Temperature: –40°C to +85°C (–40°F to +185°F)
- Operating Humidity: 5% to 85%
Optical
- Tx Wavelength: 1480 nm to 1500 nm
- Rx Wavelength: 1290 nm to 1330 nm
- Tx Power: 3 to 7 dBm
- Rx Power: –32 to –12 dBm
- Receiver Sensitivity: –32 dBm
Performance
- Tx Rate: 1.25 Gbps
- Weight: 0.035 kg (0.08 lbs.)
